Face & Plug Seal Kits for IEC 60320 C14 Inlets with IP54 Rating

The IP54 rating prevents corrosive dust and solid particles from reaching the terminals while preventing liquids from short circuiting the terminals.

Int Sized

After passing UL’s Solid Particle Protection and Liquid Ingress Protection Tests per IEC Standard 60529 (Sec. 4.2, 13.4, and 14.2.4), the C14 inlet Face Seal Kit and Plug Seal Kit from Interpower (Oskaloosa, IA) was given an Ingress Protection rating of “54” (IP54) in UL’s test report. The IP54 rating (solid particle ingress level 5, liquid ingress level 4) prevents corrosive dust and solid particles from reaching the terminals while preventing liquids from short circuiting the terminals.

The IP54-rated Face Seal and Plug Seal Kits are offered in four separate part numbers:

  • The Face Seal Kit comes in two options: C14 Screw-mount Quick Disconnect Kit, part #83050000; and the Solder Tab Kit, part #83050010. This kit includes a made-to-fit, moisture-resistant polyurethane insert which seals between the base of the C14 inlet and the face of the C13 connector, which is held in place after tightening down the connector lock.
  • The Plug Seal Kit, part #83050020 for the Quick Disconnect Kit, and part #83050030 for the Solder Tabs Kit, has a front seal made of specialized PVC with a lower durometer rating (for flexibility) that inserts through the front of the inlet to protect the terminals. While all Kits contain instructions and panel seals, the hardware (#4-40 screws and nuts) are not included.

Advantages of Interpower’s IP54 Face and Plug Seal Kits:

  • Keeps terminals dry around splashing water or other liquids
  • Prevents corrosive dust from building up around connectivity points

www.interpower.com, 800-662-2290
