UV Curing Adhesive Passes NASA Low Outgassing Specifications

UV10TK40M bonds well to glass, surface treated metals and plastics such as polycarbonates and acrylics.

Master Bond
Mb Logo

Master Bond (Hackensack, NJ) has announced the UV10TK40M, a one part UV curable system, which is not oxygen inhibited, and can be used for bonding, sealing and coating applications. UV10TK40M is optically clear, with a refractive index of 1.55. It has a high glass transition temperature (Tg) of 135-140°C and is serviceable from -60°F to +450°F. Its hardness upon curing is 75-85 Shore D. Specifically:

  • Not only does it meet NASA low outgassing specifications, but this system also withstands 1,000 hours at 85°C/85% RH.
  • Its Shore D hardness was not adversely affected even after exposure to elevated temperatures and high relative humidity.
  • UV10TK40M cures in 20-30 seconds when exposed to a UV light source emitting at a wavelength of 320-365 nm with 20-40 milliwatts per cm2.
  • UV10TK40M bonds well to glass, surface treated metals and plastics such as polycarbonates and acrylics, and is recommended in fiber-optic, optical, opto-electronic and electronic applications where heat resistance and a moderate viscosity are needed.

www.masterbond.com/products/uv-curable-systems; 201-343-8983
