Banner Engineering (Minneapolis, MN) has expanded its family of L-GAGE laser sensors with the new LTF Series. Featuring time-of-flight technology, the laser measurement sensor ensures accurate distance measurements out to 12 meters. By emitting a pulsed light, the LTF measures the amount of time for the light to reflect off the object and return to the sensor to calculate the distance. This enables sensing in long-range applications, including loop control, part presence or absence and fill level. Features include:
- A Class 2 laser emitter with small, highly visible spot, so the LTF provides easy sensor alignment and high excess gain. The same sensor that provides repeatability of less than 3 millimeters and accuracy of plus or minus 10 millimeters can also reliably detect dark targets past 7 meters and white targets at 12 meters.
- Consistent detection of targets regardless of the angle, environmental conditions or ambient light resistance. The dynamically adjusted laser sensor can also sense objects with varying materials and shapes. The laser power increases output for dark targets or objects at steep angles, while reducing power for shiny targets.
- Out of the box functionality. In just three simple steps, the sensor can be quickly mounted, aligned and provide real-time measurement. Users can also select from several TEACH modes, including 2-point teach, mid-point teach, switch point teach and push button adjust, to accommodate diverse applications. Advanced measurement modes, delay timers and cross-talk avoidance capability are also available.
www.bannerengineering.com; 888-373-6767
